VP-10

PIXL Vertex series is a new inground recessed frameless slim shape waterproof luminaire in soft and high LED or RGB version specially designed for facade and in unique structure design shape. This series are designed to offer functional, a wide range of lighting solutions and dramatic highlighting of the architectural facades of different buildings, malls through the linear curved design with superior finishing as well highest efficiency with a long service life.

Rated Power

10W/mtr

Delivered Lumen

240lm

Led Color

RGB

Beam Angle

120°

Ip Rating

IP66

Mounting

MOUNTING CLIP / CHANNEL

Dimensions

1000mm(L) x 28mm(W)

Body Finish

BLACK, GREY, WHITE

Supply Voltage

24V DC

Connection

OUTDOOR RATED CONNECTIONS

Driver / Power Supply Details

DMX

Notes

PIXEL PITCH : 16.66 PIXEL SDCM : <3

Lamp Life

50,000 Hrs

Led Quantity

60 Leds / m

Body Material

ALUMINIUM
