ZCN-Mono

PIXL ZIRCON floor tiles emit a subtle so􀈇 glow with a choice to change colors automatically through a controller compatible with DMX512 protocol. Combination of visual effects such as breathing, jumping makes the landscape design a feast for the eyes. Frequent applications include public areas landscape lighting, shopping malls, squares, plazas, driveways, walkways, patios, resorts, etc.

Rated Power

5W (500mm), 10W (1000mm)

Delivered Lumen

300-390lm @ 5W 600-700lm @ 10W

Led Color

2200/2700/3000/4000/5000/6500K/RED/BLUE/GREEN/YELLOW/AMBER

Cri

>80

Beam Angle

120°

Ip Rating

IP67

Mounting

Recessed, Surface mounted

Dimensions

300, 500, 600, 1000, 1200, 1500, 2000, 3000x17.5x13.5mm

Body Finish

STAINLESS STEEL

Supply Voltage

12V DC / 24V DC

Connection

OUTDOOR RATED CONNECTIONS

Driver / Power Supply Details

ON/OFF

Lamp Life

50,000 Hrs

Light Source

CREE / OSRAM

Body Material

HIGH STRENGTH STAINLESS STEEL
