outdoor· 9 models

LFX IP67

PIXL LFX IP67 series are flexible linear LED light strip is simple, effective solution for a wide range of lighting applications where crisp, single-color light is desired. These are mainly used in humid or wet environments which are perfect for illuminating any residential and commercial applications including bathrooms or kitchens, under cabinets and near showers or sinks.

Type: outdoor
Models: 9
Power range: 4.8–28.8 W

Request a quote

Models (9)

Model	Power	Lumens	Dimensions
DELUXE SERIES - MONO	7.2 W/mtr	648 lm/mtr (2200K) 662 lm/mtr (2700K) 684 lm/mtr (3000K) 698 lm/mtr (3500K) 720 lm/mtr (4000K) 734 lm/mtr (5000K) 756 lm/mtr (6000K) 252 lm/mtr (RED) 108 lm/mtr (BLUE) 652 lm/mtr (GREEN)	12.5mm X 5000mm X 4.8mm(PCB)	Details
DELUXE SERIES - MONO	4.8 W/mtr	432 lm/mtr (2200K) 442 lm/mtr (2700K) 456 lm/mtr (3000K) 466 lm/mtr (3500K) 480 lm/mtr (4000K) 490 lm/mtr (5000K) 504 lm/mtr (6000K) 170 lm/mtr (RED) 89 lm/mtr (BLUE) 465 lm/mtr (GREEN)	12.5mm X 5000mm X 4.8mm(PCB)	Details
DELUXE SERIES - MONO	14.4 W/mtr	1269 lm/mtr (2200K) 1325 lm/mtr (2700K) 1368 lm/mtr (3000K) 1397 lm/mtr (3500K) 1440 lm/mtr (4000K) 1469 lm/mtr (5000K) 1512 lm/mtr (6000K) 584 lm/mtr (RED) 240 lm/mtr (BLUE) 1148 lm/mtr (GREEN)	12.5mm X 5000mm X 4.8mm(PCB)	Details
DELUXE SERIES - MONO	9.6 W/mtr	864 lm/mtr (2200K) 883 lm/mtr (2700K) 912 lm/mtr (3000K) 931 lm/mtr (3500K) 960 lm/mtr (4000K) 979 lm/mtr (5000K) 1008 lm/mtr (6000K) 340 lm/mtr (RED) 177 lm/mtr (BLUE) 932 lm/mtr (GREEN)	12.5mm X 5000mm X 4.8mm(PCB)	Details
DELUXE SERIES - MONO	28.8 W/mtr	2592 lm/mtr (2700K) 2650 lm/mtr (3000K) 2736 lm/mtr (3500K) 2794 lm/mtr (4000K) 2880 lm/mtr (5000K) 2938 lm/mtr (6000K) 1100 lm/mtr (RED) 400lm/mtr (BLUE) 2200 lm/mtr (GREEN)	12.5mm X 5000mm X 4.8mm(PCB)	Details
LFX 3527 SERIES - DWWW	19.2 W/mtr	670lm/M(WHITE) 590lm/M(WARM WHITE)	14mm x 5000mm x 5mm(PCB)	Details
LFX 5050 SERIES - RGB	14.4 W/mtr	140lm/M(RED) 370lm/M(GREEN) 80 lm/M(BLUE)	10mm x 5000mm x 5mm(PCB)	Details
LFX 5050 SERIES - RGBW27K	19.2 W/mtr	79.38lm/M(RED) 293.22lm/M(GREEN) 72.90(BLUE) 288.36(WARM WHITE)	14mm x 5000mm x 5mm(PCB)	Details
LFX 5050 SERIES - RGBW65K	19.2 W/mtr	79.38(RED) 293.22(GREEN) 72.90(BLUE) 302.78(WHITE)	14mm x 5000mm x 5mm(PCB)	Details
