LINEAR HANDRAIL LIGHT-SMALL SQUARE

PIXL LED Linear handrail serve the purpose of lighting up the staircase treads as well as give an aesthetic effect to the surroundings. It is made in stainless steel and aluminum which can be installed on an existing handrail system as well as indoor or outdoor. These are waterproof IP65 rated fixture which is available in different colors ranging from 2700-6000K.

Rated Power

4W

Led Color

Tunable white/2700/3000/4000/6500K

Cri

80+

Beam Angle

10° x 110°

Ip Rating

IP65

Mounting

HANDRAIL

Dimensions

30(W) x 30(H) x 110(L)mm (Cutout 102x28mm )

Body Finish

SILVER, BLACK

Supply Voltage

24V DC

Connection

OUTDOOR RATED CONNECTIONS

Driver / Power Supply Details

ON/OFF DMX

Dimming

Non-dimmable, DMX

Lamp Life

50,000 Hrs

Light Source

PHILIPS / CREE
