outdoor· 9 models

RAIL

PIXL Handrail serve the purpose lighting up the staircase treads as well as give an aesthetic effect to the surroundings. It is made in stainless steel and aluminum which can be installed on an existing handrail system as well as indoor or outdoor. These are waterproof IP67 rated fixture which is available in different colors ranging from 2700-6000K.

Type: outdoor
Models: 9
Power range: 0.5–4 W

Request a quote

Models (9)

Model	Power	Lumens	Dimensions
FLAT RAIL ASYMMETRICAL	1.5W	—	37 x 29 mm	Details
FLAT RAIL ASYMMETRICAL	1.5W	—	33 x 39.5 mm	Details
FLAT RAIL ASYMMETRICAL	2W	—	37 x 29mm	Details
FLAT RAIL SYMMETRICAL	1.5W	—	33 x 39.5mm	Details
LINEAR HANDRAIL LIGHT-SMALL ROUND	4W	—	30(W) x 32(H) x 124(L)mm(Cutout 102x28mm )	Details
LINEAR HANDRAIL LIGHT-SMALL SQUARE	4W	—	30(W) x 30(H) x 110(L)mm (Cutout 102x28mm )	Details
LINEAR HANDRAIL LIGHT-SQUARE	0.5/1.5/2.5/3.5W	—	17.5(W) x 21(H) x 80, 180, 280, 380(L)mm(Cutout 72, 172, 272, 372x14.6mm )	Details
RAIL 2.5 Asymmetrical	1.5W	73.3 lm/W	Ø22.50 x 26.70mm	Details
RAIL 2.5 Symmetrical	1.5W	73.3lm/W	Ø22.60 x 30.50mm	Details
